Revision as of 16:51, 31 December 2018
| 24-Rescue | |
|---|---|
 | |
| Overview | |
| Year | 2019 |
| Manufacturer | Spartan |
| Type | Pumper |
| Chronology | |
| Predecessor | 2002 KME Heavy Rescue (24-Rescue) |
| At-a-Glance | |
|---|---|
| Model | Gladiator LFD |
| Sub Type | Rescue-Pumper |
| Features | |
| Pump Capacity | 1500 GPM |
| Water Capacity | 750 USG |
General
- Apparatus Type: Pumper
- Apparatus Sub Type: Rescue-Pumper
- Manufacturer: Spartan
- Year: 2019
Chassis/Cab
- Manufacturer: Spartan
- Model: Gladiator LFD
- Crew Capacity: 8
- Doors: 4
- Raised Roof: 10"
- Front Bumper: 22" extended
- Length: 166.66 inches (13 ft 10.66 in) overall, 67.5 inches (5 ft 7.5 in) crew cab
- Tilt: Full
Drivetrain
- Propulsion: Diesel
- Engine Make/Model: Cummins ISX12
- Engine Specs: 11.9 L, 500 hp, 1645 lb-ft, Inline 6
- Transmission Make/Model: Allison 4000 EVS
Pump & Tank
- Pump Make/Model: Waterous CSUC20
- Pump Capacity: 1500 GPM, single-stage
- Pump Location: Midship
- Drive Type: Split-shaft
- Water Capacity: 750 USG
Body
- Misc. Features: Roll up compartment doors
Equipment
- Generator: Harrison 10 kW
- Light Tower: Yes
- Winch: Mounted in front bumper
Dimensions
- Overall Height: 114 inches (9 ft 6 in)
- Overall Length: 400.91 inches (33 ft 4.91 in)
- Wheelbase: 202 inches (16 ft 10 in)
Construction
- Dealer: Hendrickson Fire Rescue Equipment
Disposition
CAD Drawing: 2019 Spartan 24-Rescue CAD Drawing
