8-EQ (2021)
Jump to navigation
Jump to search
| 8-EQ | |
|---|---|
 | |
| Overview | |
| Year | 2021 |
| Manufacturer | E-One |
| Type | Pumper |
| Chronology | |
| Predecessor | 2005 American LaFrance Rescue-Pumper (8-EQ) |
| At-a-Glance | |
|---|---|
| Model | Cyclone |
| Sub Type | Rescue-Pumper |
| Serial Number | 144461 |
| Features | |
| Pump Capacity | 1500 GPM |
| Water Capacity | 720 USG |
| Foam Capacity | 30 USG |
| Notable Dates | |
| Delivery | February 18, 2022 |
| In Service | June 27, 2022 |
General
- Apparatus Type: Pumper
- Apparatus Sub Type: Rescue-Pumper
- Manufacturer: E-One
- Year: 2021
- Serial Number: 144461
- VIN: 4ENLAHA80M2004461
- NIMS Resource Typing: Engine Type I
Chassis/Cab
- Manufacturer: E-One
- Model: Cyclone
- Cab Material: Aluminum
- Doors: 4
- Raised Roof: Yes
- Front Bumper: Extended with preconnect and intake
- Length: 147 inches (12 ft 3 in) overall, 74 inches (6 ft 2 in) crew cab
Drivetrain
- Propulsion: Diesel
- Engine Make/Model: Cummins X12
- Engine Specs: 500 HP
Pump & Tank
- Pump Capacity: 1500 GPM, single stage
- Pump Location: Midship
- Drive Type: Split-Shaft
- Water Capacity: 720 USG
- Foam Capacity: 30 USG
Body
- Body Type: eMax Rescue Pumper
- Material: Stainless Steel
- Length: 204 inches (17 ft 0 in)
- Misc. Features: Rollup compartment doors
Equipment
- Generator: Harrison 10 kW hydraulic
Dimensions
- Overall Height: 125 inches (10 ft 5 in)
- Overall Length: 423 inches (35 ft 3 in)
- Wheelbase: 215 inches (17 ft 11 in)
Construction
- Factory: Ocala, FL (Chassis), Hamburg, NY (Body)
- Dealer: Premier Fire Apparatus
- Delivery Date: February 18, 2022
Disposition
- In Service Date: June 27, 2022
-
CAD Drawing
