19-99 (2010)
Jump to navigation
Jump to search
| 19-99 | |
|---|---|
 | |
| Overview | |
| Year | 2010 |
| Manufacturer | Seagrave |
| Type | Aerial |
| Chronology | |
| Predecessor | 1973 Seagrave Tractor Drawn Ladder (19-99) |
| At-a-Glance | |
|---|---|
| Model | Marauder II TT06CM |
| Sub Type | Tractor Drawn Ladder |
| Serial Number | 76398 |
| Cost | $957,544 |
| Features | |
| Aerial Height | 100' |
| Notable Dates | |
| Delivery | January 14, 2011 |
| In Service | February 10, 2011 |
| Dedication | June 11, 2011 |
General
- Apparatus Type: Aerial
- Apparatus Sub Type: Tractor Drawn Ladder
- Manufacturer: Seagrave
- Year: 2010
- Serial Number: 76398
- VIN: 1F9FU38TXACST2056
- Color: White
- NIMS Resource Typing: Aerial Type II
Chassis/Cab
- Model: Marauder II TT06CM
- Cab Material: Stainless steel
- Crew Capacity: 8 plus tillerman
- Doors: 4
- Raised Roof: 8"
- Front Bumper: 18" extended
- Length: 158 inches (13 ft 2 in) overall, 72 inches (6 ft 0 in) crew cab
- Tilt: Full
- Misc. Features: Onspot chains
Drivetrain
- Propulsion: Diesel
- Engine Make/Model: Cummins ISM
- Engine Specs: 10.8 L, 500 hp, Inline 6
- Transmission Make/Model: Allison 4000 EVS
- Transmission Specs: 5-speed automatic
Aerial
- Vertical Reach: 100'
- Sections: 4
- Tip Load: 250 lb
- Prepiped Waterway: Yes
- Outriggers: A-Style
Body
- Material: Stainless steel
- Misc. Features: 331' of ground ladders
Equipment
- Generator: Harrison MAS 10kW, Hydraulic PTO
- Reels: 3 electric
Dimensions
- Overall Height: 132.5 inches (11 ft 0.5 in)
- Overall Length: 696.5 inches (58 ft 0.5 in)
- Wheelbase: 165 inches (13 ft 9 in)
Construction
- Factory: Clintonville, WI
- Cost: $957,544 (equivalent to $1,296,934 in 2023)
- Delivery Date: January 14, 2011
Disposition
- In Service Date: February 10, 2011
- Dedication Date: June 11, 2011
- Misc. History: Bond of $960,000 approved at October 20, 2009 board meeting, contract signed December 16, 2009
CAD Drawing:
2010 Seagrave 19-99 CAD Drawing
