12-78 (2017)

12-78
Overview
Year	2017
Manufacturer	Rosenbauer
Type	Aerial
Chronology
Predecessor	1995 Pierce Pumper (12-1750)

At-a-Glance
Model	Commander 4000
Sub Type	Ladder
Features
Aerial Height	78'
Pump Capacity	1500 GPM
Water Capacity	500 USG
Notable Dates
Delivery	September 13, 2018
In Service	December 8, 2018
Dedication	September 14, 2024

General

• Apparatus Type: Aerial
• Apparatus Sub Type: Ladder
• Manufacturer: Rosenbauer
• Year: 2017
• Color: White over red
• NIMS Resource Typing: Aerial Type I
• Dept. Designation: Truck #2

Chassis/Cab

• Model: Commander 4000
• Cab Material: Aluminum
• Doors: 4
• Raised Roof: 11" notched
• Front Bumper: Extended with preconnect
• Length: 114 inches (9 ft 6 in) overall, 65 inches (5 ft 5 in) crew cab
• Tilt: Full

Drivetrain

• Propulsion: Diesel
• Engine Make/Model: Cummins ISX12
• Engine Specs: 11.9 L, 500 hp, 1645 lb-ft, Inline 6

Pump & Tank

• Pump Make/Model: Hale 8FG
• Pump Capacity: 1500 GPM, single-stage
• Pump Location: Midship
• Drive Type: Split-shaft
• Water Capacity: 500 USG

Aerial

• Aerial Model: Viper
• Mounting: Rear
• Vertical Reach: 78'
• Sections: 3
• Material: Steel
• Prepiped Waterway: Yes
• Outriggers: Rear, H-Style

Body

• Body Type: FX
• Misc. Features: Roll up compartment doors

Equipment

• Generator: Harrison 10kW

Dimensions

• Overall Height: 144 inches (12 ft 0 in)
• Overall Length: 456 inches (38 ft 0 in)

Construction

• Factory: Lyons, SD
• Dealer: Garrison Fire & Rescue
• Construction Complete: March 2018
• Delivery Date: September 13, 2018

Disposition

• In Service Date: December 8, 2018
• Dedication Date: September 14, 2024

CAD Drawing: 2017 Rosenbauer CAD Drawing

•
  Cab
•
  Chassis
